JBL Synthesis SDR35 Dolby Atmos AV Receiver

JBL Synthesis SDR35 Dolby Atmos AV Receiver

• The JBL Synthesis SDR-35 is designed to ensure exceptional performance without compromise and offers an unparalleled feature set that puts it far ahead of the competition. It features full support for Dolby ATMOS, DTS:X, and Auro-3D immersive audio formats. DIRAC Live with Bass Control room EQ with JBL Synthesis system enhancements provides exceptionally accurate system tuning. A full suite of digital and analog connectivity is included along DANTE digital audio networking and HDMI 2.0b (4K Ultra HD) AV switching with support for Dolby Vision and HDR10+ dynamic video, plus IMAX Enhanced certification. Network and Bluetooth streaming are included with Google Chromecast built-in, Apple Airplay 2, Spotify Connect and Tidal Connect, plus it is Roon Ready with Hi-Res and MQA support. Seven channels of Class G amplification are included allowing the SDR-35 to independantly power systems up to 7.1 channels. Full external control allows for complete and easy system integration.

We only sell 100% Original, Top-quality JBL Synthesis Genuine Products.

Specifications

General

• Brand: Jbl
• Model: SDP-35
• Color: black

Features

• Continuous power output, per channel: 8Ω/4Ω 2 channels driven, 1kHz, 0.2% THD: 140W/220W Residual noise & hum (A-wtd): <0.15mV
• Nominal sensitivity: 1V, 2V, 4V (user adjustable) Signal/noise ratio (A-wtd ref 100W) normal/stereo direct: 100dB/110dB
• Nominal output level: 1V RMS (max. 5V RMS) THD+N (20Hz—20kHz): –100dB
• Headphone Output: Output impedance:560Ω
• Power consumption (maximum): 50W (Thermal dissipation approx. 170 BTU/hour)
• Power consumption (standby): <0.5W 2 channels driven, 20Hz - 20kHz,<0.02% THD: 120W/200W 7 channels driven, 1kHz, 0.2% THD: 100W/180W

• Maximum input: 4.5V rms
• Input impedance: 47kΩ
• Frequency response: 20Hz—20kHz ± 0.1dB
• Output impedance: 560Ω
• Headphone Output: Maximum output level into 32Ω
• Mains voltage: 110–120V or 220–240V, 50–60Hz
• Power consumption (idle, typical): 40W (Thermal dissipation approx. 170 BTU/hour)

Dimensions

• Dimension: 433 x 425 x 171mm
• Weight: 13.9kg

Warranty

• Warranty Type: Official Manufacturer Warranty
• Warranty: 1 Year
